JL AUDIO XDM600/1 Mono Class-D Amplifier

JL Audio's XDM600/1

High-tech, high-power sub amp for cars and boats

The XDM600/1 by JL Audio combines the top features of their M Series marine amplifiers and their advanced XD Series car amplifiers. This amp is constructed with marine-grade materials and showcases a selectable dual-mode power input filter for seamless performance in both marine and automotive electrical settings. With JL Audio's exclusive NexD™ ultra-high-speed and efficient amplifier technology, your bass will be played with utmost fidelity and powerful impact without any strain on your vehicle's electrical system.

Bass power and tone

Experience powerful bass with the XDM600/1 mono amp. Delivering up to 600 watts RMS to your subwoofer, its low-pass filter offers customizable slopes for superior control over your bass sound. Tighten up your system's kick and eliminate inaudible, low-frequency distractions with the built-in subsonic filter.

Works with almost any vehicle's system

This amplifier utilizes "differential-balanced" inputs, which effectively block out external interference and enable compatibility with most stereos, including factory models. Additionally, the speaker-level inputs offer dual auto turn-on modes for easy integration with factory systems. For convenient volume control, you can purchase a separate wired remote to adjust the bass from the driver's seat.

Product highlights:

• mono car/marine subwoofer amplifier
  • 400 watts RMS x 1 at 4 ohms
  • 600 watts RMS x 1 at 2 ohms
• variable low-pass filter (50-500 Hz, 12 or 24 dB/octave)
• switchable subsonic filter (30 Hz, 24 dB/oct)
• Class D amplifier design with NextD™ switching amp technology
• differential-balanced inputs help eliminate noise
• weather-resistant chassis: black powder-coat finish, gasketed control cover, stainless steel hardware

More Info:

• optional wired remote level control ( Sold Separately )
• preamp and speaker-level inputs
  • switchable input filter (car/boat) eliminates interference from onboard high-current devices
  • speaker-level inputs handle up to 4Vrms (about 4 watts)
  • speaker-level inputs require Wire-To-RCA Adapters
  • speaker-level inputs feature auto turn-on via DC offset or signal sensing
• preamp outputs
• wiring, fuse, and hardware not included with amplifier
  • 4-gauge power and ground leads and a 50-amp fuse recommended
• 8-9/16"W x 2"H x 7-1/8"D

• optional wired remote level controller not included ( sold separately )
